Open Access

Lateral lymph node metastasis in a patient with T1 upper rectal cancer treated by lateral lymph node dissection: a case report and brief literature review

Surgical Case Reports20173:93

https://doi.org/10.1186/s40792-017-0366-3

Received: 26 April 2017

Accepted: 17 August 2017

Published: 23 August 2017

Abstract

Background

Lateral lymph node (LLN) metastasis may occur in patients with advanced rectal cancers of which the lower margins are located at or below the peritoneal reflection. However, LLN metastasis from a T1 rectal cancer is rare. Here, we report a case of LLN metastasis from a T1 upper rectal cancer that was successfully treated by sequential LLN dissection.

Case presentation

A 56-year-old man was referred to our hospital for the treatment of a T1 upper rectal cancer. We performed a laparoscopic low anterior resection. Histological examination showed a moderately differentiated adenocarcinoma with submucosal layer invasion; the invasion depth was classified as head invasion, without vessel or lymph duct invasion. Tumor budding was classified as grade 1. A total of six lymph nodes were harvested, and no lymph node metastases were detected. The postoperative course was uneventful. At 6 months after surgery, however, the serum carcinoembryonic antigen levels were elevated, and abdominal computed tomography (CT) revealed swollen lymph nodes in the right internal and common iliac artery area. Positron emission tomography with CT revealed hot spots in the same lesions. A retrospective re-evaluation of the preoperative CT images revealed no apparent swollen lymph nodes; however, an unusual soft tissue area was detected around the right internal iliac artery. A right LLN dissection was performed. Fifteen lymph nodes were resected, and histologically, metastases of adenocarcinoma were identified in 3 nodes. The postoperative course was again uneventful. The patient was given 12 cycles of adjuvant chemotherapy with FOLFOX (fluorouracil, leucovorin, and oxaliplatin). The patient remains healthy and with no signs of recurrence at 30 months after the second surgery.

Conclusions

LLN metastasis occurs very rarely in patients with T1 upper rectal cancer and no risk factors for lymph node metastasis; however, a careful perioperative examination of the LLN should be performed. In cases involving LLN metastasis, a LLN dissection may be a therapeutic option if performed with curative intent.

Keywords

Lateral lymph node metastasis T1 upper rectal cancer Lateral lymph node dissection Perioperative examination

Background

The standard treatment for T1 rectal cancer is total mesorectal excision (TME) without preoperative chemoradiotherapy in Western countries and TME without lateral lymph node (LLN) dissection in Japan [13]. LLN metastases are detected in approximately 15% of patients with rectal cancer; however, LLN metastases from T1 rectal cancers are rare [46]. Here, we report a case of LLN metastasis from a T1 upper rectal cancer that was successfully treated by sequential LLN dissection.

Case presentation

A 56-year-old man was referred to our hospital for the treatment of rectal cancer. The patient was otherwise healthy, without significant previous or current medical problems. His serum carcinoembryonic antigen (CEA) and carbohydrate antigen 19-9 levels were 1.8 ng/mL (normal, <3.4 ng/mL) and 7.7 U/mL (normal, <37 U/mL), respectively. Colonoscopy revealed a pedunculated-type tumor measuring 1.5 cm × 1.0 cm in the upper rectum, 12 cm from the anal verge, and proctographic examination revealed a filling defect in the upper rectum (Fig. 1a, b). Contrast-enhanced computed tomography (CT) revealed no swollen lymph nodes or distant metastases. We diagnosed the rectal cancer as T1N0M0 stage I and performed a laparoscopic low anterior resection. Regarding the extent of lymph node dissection, a division of the superior rectal artery root was performed without LLN dissection. A histological examination revealed a moderately differentiated adenocarcinoma that had invaded the submucosal layer (T1); the invasion depth was classified as a head invasion, without vessel or lymph duct invasion (Fig. 2a–c). Tumor budding was classified as grade 1. A total of six lymph nodes were harvested, and no lymph node metastases were detected. The postoperative course was uneventful.
Fig. 1

Endoscopic and proctographic findings. a Colonoscopy revealed a pedunculated-type tumor measuring 1.5 cm × 1.0 cm. b Proctographic examination revealed a filling defect in the upper rectum (arrow)

Fig. 2

Histological examination showed a moderately differentiated adenocarcinoma that had invaded the submucosal layer; the invasion depth was classified as a head invasion (a). Immunohistochemical staining for CD34 (b) and D2-40 (c) revealed no infiltration of the vessels or lymph ducts. d The resected lateral lymph nodes confirmed a metastasis of moderately differentiated adenocarcinoma

Six months after the operation, however, the patient’s serum CEA levels increased to 7.0 ng/mL. Abdominal CT revealed swollen lymph nodes in the right common and internal iliac artery area (Fig. 3a, b). Positron emission tomography (PET) with CT revealed hot spots (SUVmax, 5.3) in the same lesions (Fig. 4a, b). No other metastases were observed. Accordingly, we retrospectively re-evaluated the preoperative CT images. Although we detected no apparent swollen lymph nodes, we observed an unusual soft tissue area around the right internal iliac artery (Fig. 5). The preoperative diagnosis was an LLN metastasis localized in the right pelvic area, and an open unilateral LLN dissection of the right common iliac, internal iliac, and obturator nodes was performed. The branches of the right internal iliac vessels, including the superior vesical and obturator vessels, were ligated and divided at their origins with resected lymph nodes; however, the internal iliac artery and pelvic nerve plexus were preserved. Histologically, 15 lymph nodes were resected; of these, 3 (2 in the proximal internal iliac node and 1 in the common iliac node) contained metastases of adenocarcinoma (Fig. 2d). The postoperative course was uneventful. The patient was given 12 cycles of adjuvant chemotherapy with FOLFOX (fluorouracil, leucovorin, and oxaliplatin). He remains healthy without signs of recurrence at 30 months after the second surgery.
Fig. 3

Contrast-enhanced computed tomography. Images show swollen lymph nodes a in the right common iliac artery area (arrow) and b right internal iliac artery area (arrowhead)

Fig. 4

Positron emission tomography. Images show hot spots a in the right common iliac artery area and b right internal iliac artery area

Fig. 5

Contrast-enhanced computed tomography performed prior to initial surgery. The image shows an unusual area of soft tissue around the right internal iliac artery (arrow)

Discussion

The course of the patient described in this report suggests two important clinical issues. First, LLN metastasis can occur in a patient with T1 upper rectal cancer and no risk factors for lymph node metastasis; second, sequential LLN dissection is useful for the treatment of this condition.

With regard to the first point, LLN metastasis occurs in 7.7–28.8% of patients with T3–T4 lower rectal cancer [4]. In contrast, the reported incidence of LLN metastasis among patients with T1 lower rectal cancer is only 0.9% [4]. To date, only four cases of isolated LLN metastasis from a lower rectal cancer have been reported [710], and to our knowledge, ours is the first case of LLN metastasis in a patient with T1 upper rectal cancer. The incidence of lymph node metastasis from a T1 colorectal cancer is approximately 15% [3]. Additional major surgery is recommended after a successful endoscopic excision if the tumor has at least one risk factor for lymph node metastasis, including an invasion depth ≥1000 μm from the muscularis mucosa, lymphatic and vascular invasion, non-well or moderately differentiated adenocarcinoma, and high-grade budding [3]. Table 1 presents a review of the five reported cases (including this case) of isolated LLN metastasis from T1 rectal cancer. Three of the five cases had risk factors for lymph node metastasis [810]; in contrast, our case had no identified risk factors and involved a pedunculated-type tumor with head invasion that could be managed by endoscopic treatment alone [11].
Table 1

Review of four reported cases (including the present case) of isolated LLN metastasis from a T1 rectal cancer

Case

Year

Author

Age (years)

Sex

Location of primary tumor

Risk factors of lymph node metastasis

Depth of invasion (μm)

Histological type

ly

v

Budding grade

1

2008

Hara

61

Male

Lower

Well

0

0

2

2010

Yamaguchi

67

Female

Lower

3000

Well to moderately

0

0

3

2013

Sueda

41

Female

Lower

Moderately

0

Positive

4

2016

Ogawa

35

Female

Lower

3000

Moderately

Positive

0

5

2017

Ours

56

Male

Upper

Head invasion

Moderately

0

0

1

LLN lateral lymph node, not described

In general, enhanced CT is used as a preoperative imaging tool for rectal cancer. Currently, the European Society for Medical Oncology guidelines recommend pelvic magnetic resonance imaging (MRI) for the initial staging of rectal cancer because this modality is highly accurate for determining localization, clinical T and N stages, and potential circumferential resection margins [1]. The diagnostic sensitivity and specificity of MRI for lymph node metastasis are 77 and 71%, respectively [12]. Additionally, the usefulness of diffusion-weighted imaging (DWI)-MRI has recently been reported [1315]. The accuracy of DWI-MRI is better than that of both CT and 18FDG-PET (86.6 vs. 76.0% and 78.3 vs. 69.9%, respectively) [14, 15]. In our case, we considered the patient to be metastasis-negative, based on enhanced CT findings. The LLN metastasis was revealed only 6 months after the initial surgery, when an unusual soft tissue area around the right internal iliac artery was retrospectively detected on preoperative CT images. Based on these two factors, it is possible that the LLN metastasis existed at the time of initial surgery and could have been diagnosed by DWI-MRI.

With regard to the second point about the therapeutic usefulness of sequential LLN dissection, the status of the LLN has not been fully established. In Japan, LLN metastasis is considered a local disease [16], and prophylactic LLN dissection is recommended [3]. This type of dissection does not appear to increase morbidity, mortality, or sexual dysfunction [17, 18]. In Western countries, LLN is categorized as a distant metastasis, and preoperative chemoradiotherapy, rather than prophylactic LLN dissection, has been administered to patients with advanced rectal cancers [l, 2]. However, therapeutic LLN dissection is recommended at the time of primary tumor resection for cases with clinically evident LLN metastasis, assuming that curative resection can be achieved [19]. Extended LLN dissection is recommended due to favorable oncologic outcomes in this situation [6, 7]. Table 2 lists the treatments and outcomes of the five cases of isolated LLN metastasis from T1 rectal cancer. In four cases, extended LLN dissection was performed [710]. We disagree with the LLN dissection with skeletonizing of the branches of the internal iliac vessels; however, we think a routine en bloc resection of the internal iliac vessels is not necessary when the metastatic tumors do not invade or adhere firmly to the internal iliac vessels because there is the possibility of increasing the risk of complications. In our case, the internal iliac vessels were preserved, while the branches of the internal iliac vessels, including the superior vesical and obturator vessels, were resected with the lymph nodes. Bilateral LLN dissection has greater benefits on reducing local recurrence than unilateral LLN dissection [20]; however, in all four cases, the patients with isolated LLN metastases from early rectal cancers were treated successfully via unilateral LLN dissection in the affected side [710]. With regard to adjuvant chemotherapy, two patients refused chemotherapy after LLN dissection [7, 9].
Table 2

Treatments and outcomes of the four reported cases of isolated LLN metastasis from a T1 rectal cancer

Case

Time after 1st surgery (months)

Treatment

Bilateral or unilateral LLND

Chemotherapy after LLLD

Outcome and time after LLND (months)

1

22

Extended LLND

Unilateral

None

Alive

2

Synchronous

Extended LLND

Unilateral

5-Fluorouracil

Alive

3

6

Extended LLND

Unilateral

None

Alive

4

Synchronous

Extended LLND

Unilateral

Tegafur-uracil + leucovorin

Alive

5

6

LLND

Unilateral

FOLFOX

Alive

LLND lateral lymph node dissection, FOLFOX fluorouracil, leucovorin, and oxaliplatin

Conclusions

LLN metastasis can occur in patients with T1 upper rectal cancer and no risk factors for lymph node metastasis, and sequential LLN dissection is useful for the treatment of this condition. Although LLN metastasis occurs very rarely in this patient population, a careful perioperative evaluation of the LLN should be performed. In cases involving LLN metastasis, LLN dissection could be considered a therapeutic option if performed curatively.

Abbreviations

CEA:

Carcinoembryonic antigen

CT:

Computed tomography

DWI:

Diffusion-weighted imaging

LLN:

Lateral lymph node

MRI:

Magnetic resonance imaging

PET:

Positron emission tomography

Declarations

Funding

No funding was received for this case report.

Authors’ contributions

HT, MK, TT, SI, and TH performed the surgery, YH diagnosed the pathology, and TH approved the final manuscript. All authors read and approved the final manuscript.

Consent for publication

Written informed consent was obtained from the patient for publication of this case report and any accompanying images.

Competing interests

The authors declare that they have no competing interest.

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.

Authors’ Affiliations

(1)
Department of Surgery, National Hospital Organization, Osaka Minami Medical Center
(2)
Department of Pathology, National Hospital Organization, Osaka Minami Medical Center

References

  1. Schmoll HJ, Van Cutsem E, Stein A, Valentini V, Glimelius B, Haustermans K, et al. ESMO consensus guidelines for management of patients with colon and rectal cancer. A personalized approach to clinical decision making. Ann Oncol. 2012;23:2479–516.View ArticlePubMedGoogle Scholar
  2. National Comprehensive Cancer Network, NCCN clinical practice guidelines in oncology, rectal cancer. Ver. 3. 2017. (https://www.nccn.org/professionals/physician_gls/pdf/rectal.pdf).
  3. Watanabe T, Itabashi M, Shimada Y, Tanaka S, Ito Y, Ajioka Y, et al. Japanese Society for Cancer of the Colon and Rectum (JSCCR) guidelines 2014 for treatment of colorectal cancer. Int J Clin Oncol. 2015;20:207–39.View ArticlePubMedPubMed CentralGoogle Scholar
  4. Sugihara K, Kobayashi H, Kato T, Mori T, Mochizuki H, Kameoka S, et al. Indication and benefit of pelvic sidewall dissection for rectal cancer. Dis Colon rectum. 2006;49:1663–72.View ArticlePubMedGoogle Scholar
  5. Kobayashi H, Mochizuki H, Kato T, Mori T, Kameoka S, Shirouzu K, et al. Outcomes of surgery alone for lower rectal cancer with and without pelvic sidewall dissection. Dis Colon rectum. 2009;52:567–76.View ArticlePubMedGoogle Scholar
  6. Moriya Y, Sugihara K, Akasu T, Fujita S. Importance of extended lymphadenectomy with lateral node dissection for advanced lower rectal cancer. World J Surg. 1997;21:728–32.View ArticlePubMedGoogle Scholar
  7. Hara J, Yamamoto S, Fujita S, Akasu T, Moriya Y. A case of lateral pelvic lymph node recurrence after TME for submucosal rectal carcinoma successfully treated by lymph node dissection with en bloc resection of the internal iliac vessels. Jpn J Clin Oncol. 2008;38:305–7.View ArticlePubMedGoogle Scholar
  8. Yamaguchi T, Yamamoto S, Fujita S, Akasu T, Kobayashi Y, Moriya Y. Early lower rectal carcinoma with synchronous isolated lateral pelvic lymph node metastasis: report of a case. J Jpn Coll Surg. 2010;35:799–803.Google Scholar
  9. Sueda T, Noura S, Ohue M, Shingai T, Imada S, Fujiwara Y, et al. Case of isolated lateral lymph node recurrence occurring after TME for T1 lower rectal cancer treated with lateral lymph node dissection: report of a case. Surg Today. 2013;43:809–13.View ArticlePubMedGoogle Scholar
  10. Ogawa S, Itabashi M, Hirosawa T, Hashimoto T, Bamba Y, Okamoto T. Diagnosis of lateral pelvic lymph node metastasis of T1 lower rectal cancer using diffusion-weighted magnetic resonance imaging: a case report with lateral pelvic lymph node dissection of lower rectal cancer. Mol Clin Oncol. 2016;4:817–20.PubMedPubMed CentralGoogle Scholar
  11. Matsuda T, Fukuzawa M, Uraoka T, Nishi M, Yamaguchi Y, Kobayashi N, et al. Risk of lymph node metastasis in patients with pedunculated type early invasive colorectal cancer: a retrospective multicenter study. Cancer Sci. 2011;102:1693–7.View ArticlePubMedGoogle Scholar
  12. Al-Sukhni E, Milot L, Fruitman M, Beyene J, Victor JC, Schmocker S, et al. Diagnostic accuracy of MRI for assessment of T category, lymph node metastases, and circumferential resection margin involvement in patients with rectal cancer: a systematic review and meta-analysis. Ann Surg Oncol. 2012;19:2212–23.View ArticlePubMedGoogle Scholar
  13. Zhao Q, Liu L, Wang Q, Liang Z, Shi G. Preoperative diagnosis and staging of rectal cancer using diffusion-weighted and water imaging combined with dynamic contrast-enhanced scanning. Oncol Lett. 2014;8:2734–40.PubMedPubMed CentralGoogle Scholar
  14. Mizukami Y, Ueda S, Mizumoto A, Sasada T, Okumura R, Kohno S, et al. Diffusion-weighted magnetic resonance imaging for detecting lymph node metastasis of rectal cancer. World J Surg. 2011;35:895–9.View ArticlePubMedGoogle Scholar
  15. Ono K, Ochiai R, Yoshida T, Kitagawa M, Omagari J, Kobayashi H, et al. Comparison of diffusion-weighted MRI and 2-[fluorine-18]-fluoro-2-deoxy-D-glucose positron emission tomography (FDG-PET) for detecting primary colorectal cancer and regional lymph node metastases. J Magn Reson Imaging. 2009;29:336–40.View ArticlePubMedGoogle Scholar
  16. Akiyoshi T, Watanabe T, Miyata S, Kotake K, Muto T, Sugihara K, Japanese Society for Cancer of the Colon and Rectum. Results of a Japanese nationwide multi-institutional study on lateral pelvic lymph node metastasis in low rectal cancer: is it regional or distant disease? Ann Surg. 2012;255:1129–34.View ArticlePubMedGoogle Scholar
  17. Fujita S, Akasu T, Mizusawa J, Saito N, Kinugasa Y, Kanemitsu Y, et al. Postoperative morbidity and mortality after mesorectal excision with and without lateral lymph node dissection for clinical stage II or stage III lower rectal cancer (JCOG0212): results from a multicentre, randomised controlled, non-inferiority trial. Lancet Oncol. 2012;13:616–21.View ArticlePubMedGoogle Scholar
  18. Saito S, Fujita S, Mizusawa J, Kanemitsu Y, Saito N, Kinugasa Y, et al. Male sexual dysfunction after rectal cancer surgery: results of a randomized trial comparing mesorectal excision with and without lateral lymph node dissection for patients with lower rectal cancer: Japan clinical oncology group study JCOG0212. Eur J Surg Oncol. 2016;42:1851–8.View ArticlePubMedGoogle Scholar
  19. Monson JR, Weiser MR, Buie WD, Chang GJ, Rafferty JF, Buie WD, et al. Practice parameters for the management of rectal cancer (revised). Dis Colon rectum. 2013;56:535–50.View ArticlePubMedGoogle Scholar
  20. Kusters M, van de Velde CJ, Beets-Tan RG, Akasu T, Fujita S, Yamamoto S, Moriya Y. Patterns of local recurrence in rectal cancer: a single-center experience. Ann Surg Oncol. 2009;16:289–96.View ArticlePubMedGoogle Scholar

Copyright

© The Author(s). 2017
